Name: CityBuildings

Display Field: created_user

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: In 2022, the Virginia Geographic Information Network contracted with Surdex to capture planimetrics for various localities across Virginia. The City of Harrisonburg took part in this program and is where this building layer originated. Updates will be done on this layer until the next planimetric cycle in 2026, at which point this layer will be archived. Demolished buildings are not present in this feature layer. Elevation information stems from the 2020 USGS LIDAR collection and captured data present from 11/29/2020 to 1/12/2021. Caution must be taken for any building constructed after this date since it would not of been captured in the LIDAR collection. All elevation data is in meters and based off the NAVD88 vertical datum.The workflow for creating layer:Create building layer from structure layer provided in the planimetrics.Select for all Edit Types except "Deleted", which are buildings not present anymore since the last planimetric update. Then select for the following types: building, deck, smokestack, and water tower. Create new layer from this selection, this will be the new CityBuilding layer.Remove any buildings further than 250 feet from the city boundary.If there is a gap between the date the building data was created and the date this layer is made, add any newly constructed buildings. LAMA holds this information and site plans can be digitized to create them.Populate relevant attribute fields.

Service Item Id: ab6ec27170b44601bbb90b718e354d26

Copyright Text: Commonwealth of Virginia, VGIN, City of Harrisonburg

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.1323081940225497E7
YMin: 6822197.66054748
XMax: 1.1392380260289997E7
YMax: 6872283.242790818
Spatial Reference: 102746  (2283)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Type
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: BUILDING
  Label: BUILDING
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [178, 178, 178, 255]
  Outline:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 1
• Value: DECK
  Label: DECK
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [115, 76, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 1
• Value: SMOKESTACK
  Label: SMOKESTACK
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [230, 76, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 1
• Value: WATER TOWER
  Label: WATER TOWER
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [63, 155, 191, 255]
  Outline:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Type ( type: esriFieldTypeString, alias: Type, length: 36 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• BldgSrc ( type: esriFieldTypeString, alias: Building Source, length: 100 )
• EditType ( type: esriFieldTypeString, alias: Edit Type, length: 100 )
• HistDist ( type: esriFieldTypeString, alias: Downtown Historic District, length: 10 )
• BusiDist ( type: esriFieldTypeString, alias: Downtown Business District, length: 10 )
• MinHeight ( type: esriFieldTypeDouble, alias: Minimum Height )
• MaxHeight ( type: esriFieldTypeDouble, alias: Maximum Height )
• MeanHeight ( type: esriFieldTypeDouble, alias: Mean Height )
• BaseElev ( type: esriFieldTypeDouble, alias: Base Elevation )
• HeightUnit ( type: esriFieldTypeString, alias: Height Units, length: 20 )
• HeightSrc ( type: esriFieldTypeString, alias: Height Source, length: 50 )
• EsriType ( type: esriFieldTypeString, alias: Esri Community Map Type, length: 255 )
• EsriLabel ( type: esriFieldTypeString, alias: Esri Community Map Label, length: 255 )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 255 )
• UniqueID ( type: esriFieldTypeInteger, alias: UniqueID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
